ZKTeco inBio160 POE Bundle: Fingerprint Matching Panels

Description

ZKTeco inBio160 PoE Bundle: Single-Door Biometric Access Control Panel with Integrated PoE for Simplified Installation

The ZKTeco inBio160 PoE Bundle is an advanced, IP-based biometric access control panel designed for managing access to a single door. This bundle features Power over Ethernet (PoE) technology, which simplifies installation by providing both power and data transmission through a single Ethernet cable. This reduces wiring complexity, making it a cost-effective and efficient solution for various access control needs.

The inBio160 PoE Bundle includes advanced biometric capabilities, with fingerprint matching performed directly on the panel to enhance security. The system supports up to 3,000 fingerprint templates, 30,000 card users, and stores up to 100,000 event transactions. It is compatible with ZKTeco’s FR Series fingerprint readers via RS-485, and it can also accommodate traditional RFID readers through Wiegand inputs. The panel’s advanced access control features, such as Anti-Passback, First-Card Opening, Multi-Card Opening, and Duress Password Entry, make it a robust solution for secure access management.

Key Features

• Single-Door Access Control – Designed for secure management of a single door with advanced biometric capabilities.
• Power over Ethernet (PoE) – PoE integration simplifies installation by providing both power and data through a single cable.
• Biometric Verification – Performs fingerprint matching directly on the panel for enhanced security and reduced reliance on external devices.
• Reader Compatibility – Supports ZKTeco’s FR Series fingerprint readers via RS-485 and traditional RFID readers through Wiegand inputs.
• Advanced Access Control Functions – Features Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and auxiliary input/output linkages for comprehensive access management.

Technical Specifications

• Number of Doors Controlled: One
• Number of Readers Supported: Two (Fingerprint or Wiegand readers)
• User Capacity: 30,000 users
• Fingerprint Capacity: 3,000 templates
• Event Transaction Capacity: 100,000 logs
• Communication: TCP/IP, RS-485
• Power Supply: Nominal voltage of 12V; standby current of 50mA
• Operating Temperature: 0°C to 45°C
• Operating Humidity: 20% to 80%
• Dimensions: 305.2mm × 298.4mm × 89mm (Bundle); 183mm × 106mm (Board)

Applications

The ZKTeco inBio160 PoE Bundle is ideal for environments that require secure and efficient single-door access control, such as corporate offices, data centers, and restricted areas. Its biometric capabilities, combined with PoE integration, provide a streamlined and cost-effective solution for modern access management needs.

Why Choose ZKTeco inBio160 PoE Bundle?

• Effortless Installation – PoE integration reduces wiring complexity and installation costs, making it a convenient choice for access control.
• Enhanced Security – Biometric fingerprint matching performed directly on the panel enhances security and prevents unauthorized access.
• Scalable Solution – Supports up to 30,000 users and 3,000 fingerprint templates, providing scalability for growing businesses.
