A high-performance 4K fisheye camera offering clear video monitoring with face detection and intelligent video analytics. It features a built-in P2P cloud function for flexible remote viewing.
The ZKTeco DL-858V17C-FS, also known as P series 4K fisheye camera, is equipped with a panoramic lens and on-board de-warp correction which is capable of covering the whole surrounding area with high-quality picture image[^1^][1][^2^][2]. This model comes with an embedded face detection algorithm and supports multiple industry-leading Intelligent video analytic functions[^1^][1].
One of the standout features of this model is the built-in P2P cloud function. This allows for more convenient and flexible remote real-time viewing and monitoring[^1^][1]. The camera also utilizes H.265+ dual-stream encoding, an evolutionary optimization of H.265 and the traditional H.264[^1^][1]. It includes a series of encoding strategies such as dynamic ROI, smart 2D&3D noise reduction for delivering high-quality videos while greatly saving up to 70% bandwidth and storage[^1^][1].
With precise mechanical design and rugged metal casing rated IP67, this camera can withstand water and dust for a long time. It can work safely under extreme or unstable power conditions and adapt to a variety of harsh outdoor environments with a working temperature range from -10°C ~ 50°C[^1^][1].
| Feature | Description |
|---|---|
| Model | DL-858V17C-FS |
| Image Sensor | 1/1.7” Sony CMOS |
| Effective Pixels | 3840 * 2160 |
| Min. Illumination | Colour: 0.1Lux / F1.4 (AGC ON); B/W: 0 Lux with IR ON |
| Flash / DDR | 128Mb / 256Mb |
| IR LED No. | 4 |
| IR Distance | 10 ~ 20m |
| S/N Ratio | > 52dB |
| Lens Type | Fisheye Lens |
| Mount Type | N/A |
| Focal Length | N/A |
| Aperture | F1.4 |
| FOV | 360° |
| Optical Zoom | N/A |
| Compression | H.265 / H.264 |
| Resolution | 8MP (3840 * 2160) / 1080P (1920 * 1080) / 1.3M (1280 * 960) / 720P (1280 * 720) / D1 (704 * 576) / CIF (352 * 288) |
| Bitrate Control | CBR / VBR |
| Bitrate | 32Kbps - 16Mbps |
| Main Stream | 4K@30fps / 5M@30fps / 4MP@30fps / 3MP@30fps / 2MP@30fps |
| Sub Stream | 720P@30fps / D1@30fps / CIF@30fps |
| Third Stream | N/A |
| Motion Detection | Support |
| Digital Zoom | Support |
| Audio Compression | G7.11u |
| Privacy Mask | 5 areas |
| WDR | TWDR |
| Day / Night | Support |
| White Balance | Support |
| Defog | Support |
| Noise Reduction | 2D/3D DNR |
| Mirror / Flip | Support |
| Corridor Mode | Support |
| HLC | Support |
| BLC | Support |
| ROI | 4 areas |
| Anti-flicker | Support |
| IVA | Intelligent Video |
| Special Feature | N/A |
| Network Protocol | TCP/IP, UDP, HTTP, IGMP, ICMP, DHCP, RTP / RTSP, DNS, DDNS, FTP, NTP, PPPoE, UPNP, SMTP, SNMP |
| Interoperability | ONVIF Profile S, SDK, API |
| Max. Online Users | 5 |
| Web Browser | IE / Firefox / Chrome / Safari |
| Note | Video streaming is not available for Firefox / Chrome / Safari. |
| Management Software (VMS) | AntarVis 2.0 / ZKBioSecurity IVS / ZKBio Access IVS |
| Operation System | Windows |
| Mobile Application | AntarView Pro |
| P2P Cloud Service | Support |
| Ethernet | 1 RJ-45 port (10/100Mbps) |
| Audio I/O | 1 in / 1 out |
| Alarm I/O | 1 in / 1 out |
| RS485 | Support |
| Reset Button | N/A |
| Micro-SD Slot | Support (Max 128GB) |
| ANR | Support |
| USB | N/A |
| Power Supply | PoE (IEEE802.3af ), DC 12V±10% |
| Power Consumption | < 5W |
| Ingress Protection | IP66 |
| Dimensions | Φ149.4 * 50 mm |
| Working Temperature | -10°C ~ 50°C |
| Working Humidity | 10% ~ 90% |
| Net Weight | 2.0kg |
| Gross Weight | 2.0kg |
| Ordering Information - Camera | 8MP Camera |
| Model | DL-858V17C-FS |
| Description | 8MP Fisheye IP Camera |
